| SIZE | Diameter (mm) | Mass Per M (kg) | Mass Per Pieces 10 M (kg) | Mass Per Pieces 12 M (kg) | Cross Sectional Area (sq.mm) |
| DB10 | 10 | 0.616 | 6.160 | 7.932 | 78.54 |
| DB12 | 12 | 0.888 | 8.880 | 10.656 | 113.1 |
| DB16 | 16 | 1.578 | 15.780 | 18.936 | 201.06 |
| DB20 | 20 | 2.466 | 24.660 | 29.592 | 314.16 |
| DB22 | 22 | 2.984 | 29.840 | 35.808 | 380.13 |
| DB25 | 25 | 3.853 | 38.530 | 46.236 | 490.87 |
| DB28 | 28 | 4.834 | 48.340 | 58.008 | 615.75 |
| DB32 | 32 | 6.313 | 63.130 | 75.756 | 804.25 |
| DB36 | 36 | 7.99 | 79.900 | 95.880 | 1017.88 |
| DB40 | 40 | 9.865 | 98.650 | 118.380 | 1256.64 |
